Install Docker-Compose

Install Docker-Compose

Get Social!

Docker-compose is a utility used to create and manage multiple Docker containers together to form a service. It relies on Docker being installed on the same host so make sure that Docker is installed on your system beforehand. Once you have docker installed and tested you’re ready to begin.

It’s worth noting that docker-compose is often available with your Linux distributions package manager, such as apt or yum but you may find they’re often out of date.

Manually installing docker-compose

Manually installing docker-compose is made easy by the fact that the docker-compose binary is a single file. The process is simple; grab the binary, put it in the right place and make it executable.

In addition to Docker, you’ll need curl installed to download the docker-compose binaries.

apt install curl
# Or
yum install curl

Once you have curl installed it’s time to install docker-compose. The below link will install the latest ‘stable’ release – if you need a different release you’ll need to check the github page for the version number you require.

Run the below commands to download docker-compose and link the binary to your linux bin directory.

curl -L "https://github.com/docker/compose/releases/latest/download/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
chmod +x /usr/local/bin/docker-compose

Test docker-compose

Finally, to test your docker-compose is working, run the below command to output the version of docker-compose. At the time of writing, the latest version was 1.24.1, but this will move as time goes on.

docker-compose --version
docker-compose version 1.24.1, build 4667896b


DataStax Cassandra 3.2 Bash Install Script

Get Social!

The below script installs the DataStax distribution of Cassandra 3.2.x and the latest Oracle Java 8 on Debian. Copy and paste the script into a file called install_cassandra.sh and execute it as root.

Change the version 3.2 on line 12 to match the version you’d like to install.

#!/bin/bash
set -e

apt-get update
apt-get install -y wget curl

echo "Installing repos"
echo "deb http://ppa.launchpad.net/webupd8team/java/ubuntu xenial main" | tee /etc/apt/sources.list.d/webupd8team-java.list
echo "deb-src http://ppa.launchpad.net/webupd8team/java/ubuntu xenial main" | tee -a /etc/apt/sources.list.d/webupd8team-java.list
apt-key adv --keyserver hkp://keyserver.ubuntu.com:80 --recv-keys EEA14886

echo "deb http://debian.datastax.com/datastax-ddc 3.2 main" | tee -a /etc/apt/sources.list.d/cassandra.sources.list
curl -L https://debian.datastax.com/debian/repo_key | apt-key add -


echo "Installing binaries"
apt-get update
echo oracle-java7-installer shared/accepted-oracle-license-v1-1 select true | /usr/bin/debconf-set-selections
apt-get install -y oracle-java8-installer datastax-ddc

echo "Complete"

Then connect to the local Cassandra instance run the cqlsh tool.

cqlsh

Connected to Test Cluster at 127.0.0.1:9042.
[cqlsh 5.0.1 | Cassandra 3.2.1 | CQL spec 3.4.0 | Native protocol v4]
Use HELP for help.
cqlsh>




Automated Bash MongoDB 3.2 Install Script for Debian/ Ubuntu

Get Social!

mongodb-logoMongoDB is one of the leading noSQL breeds of database that’s been growing in popularity in recent years. The database is available in a ‘community edition’ that’s available for all to use freely.

The database setup and install is mostly straightforward however there are a few steps you have to take to get a MongoDB instance up and running.

The binaries aren’t shipped by the common Linux distributions so you’ll need to add the apt repositories hosted by mongodb.org. After installing the binaries there are a few config options that can be helpful to start with that are not contained in the default MongoDB install.

First off, create a file on your server called install_mongo.sh and copy the content of the script into it found in the below link.

MongoDB 3.2 Bash Install Script

vi install_mongo.sh

Then make the script executable and run it.

chmod +x install_mongo.sh
./install_mongo.sh

Once the script completes you’ll be able to connect to your MongoDB instance with adminadmin.

mongo admin -u admin -p admin

MongoDB shell version: 3.2.7
connecting to: admin
rs1:PRIMARY>

What the MongoDB install script does

The following is a brief outline of the steps the script takes:

  1. Add the apt repository from mongodb.org and associated key.
  2. Install the full mongo-org package containing these packages: mongodb-org-server, mongodb-org-mongos, mongodb-org-shell, mongodb-org-tools.
  3.  Add a basic config file that:
    1. Enforces the wiredTiger storage engine.
    2. Enables remote access by listening on ALL interfaces.
    3. Enables replication, even if it’s just a stand alone node.
    4. Enables user authentication.
  4. Initiates the server as a replication cluster.
  5. Adds a user for administration called admin with password admin.




MongoDB 3.2 Bash Install Script

Get Social!

The below script installs MongoDB 3.2.x on Debian. Copy and paste the script into a file called install_mongo.sh and execute it as root.

#!/bin/bash
set -e

echo "Installing repo"
apt-key adv --keyserver hkp://keyserver.ubuntu.com:80 --recv EA312927

echo "deb http://repo.mongodb.org/apt/debian wheezy/mongodb-org/3.2 main" > /etc/apt/sources.list.d/mongodb-org-3.2.list


echo "Installing binaries"
apt-get update
apt-get install -y mongodb-org
service mongod stop


echo "Setting up default settings"
rm -rf /var/lib/mongodb/*
cat > /etc/mongod.conf <<'EOF'
storage:
  dbPath: /var/lib/mongodb
  directoryPerDB: true
  journal:
    enabled: true
  engine: "wiredTiger"

systemLog:
  destination: file
  logAppend: true
  path: /var/log/mongodb/mongod.log

net:
  port: 27017
  bindIp: 0.0.0.0
  maxIncomingConnections: 100

replication:
  oplogSizeMB: 128
  replSetName: "rs1"

security:
  authorization: enabled

EOF

service mongod start
sleep 5

mongo admin <<'EOF'
use admin
rs.initiate()
exit
EOF

sleep 5

echo "Adding admin user"
mongo admin <<'EOF'
use admin
rs.initiate()
var user = {
  "user" : "admin",
  "pwd" : "admin",
  roles : [
      {
          "role" : "userAdminAnyDatabase",
          "db" : "admin"
      }
  ]
}
db.createUser(user);
exit
EOF

echo "Complete"

Then connect to the local MongoDB instance

mongo admin -u admin -p admin

MongoDB shell version: 3.2.7
connecting to: admin
rs1:PRIMARY>




Small Scale Ceph Replicated Storage

Category : How-to

Get Social!

I’ve written a few posts about Ceph, how it works and how it’s set up and it mostly revolves around large scale storage for storing things like virtual machines. This post will focus on using Ceph  provide fault tolerant storage for a small amount of data in a low resource environment. Because of this, the main focus has been moved away from performance and switched to:

  • availability – the storage should always be available and recoverable in the event of disaster
  • portability – the storage isn’t tied to a machine and can be moved with relative ease.
  • scalability – more machines can use the storage as required.

This tutorial will focus on a small scale Ceph setup, fit for something like a Raspberry Pi or low resource VPS. We’ll use 3 machines but you could easily add more machines if your scenario requires it.

If you are looking for a larger setup, then see this blog post on installing Ceph.

ceph-local

The above diagram shows the topology of the layout. Each machine will have a file /ceph-file that will be mounted as a block device on /dev/loop0 and that’s the space that will be assigned to Ceph. Ceph will replicate any data stored to the file and ensure the data is available to all Ceph clients. The Ceph storage will be accessed from a mountpoint at /mnt/ha-pool.

Ceph block device

The first step in creating a Ceph storage pool is to set aside some storage that can be used by Ceph. Ceph stores everything twice, by default, so whatever storage you provision will be halved. For this example we’re going to use a file created with dd as the Ceph storage device, however you could use a drive mounted in /dev/ if you have one. A whole drive is by far the preferred solution, however as I’ve stated, the main goal of this post isn’t just performance.

If you’re going to use a file for storage, follow my post on creating a block device from a file and mount it on loop0. Otherwise you can continue to the next step.

OpenVZ: if you’re using Ceph inside of an OpenVZ container, make sure you pass the loop device through to the container.

Installing Ceph

At this point it’s worth noting that Ceph, in addition to the application requirements, will use approximately 1MB of RAM for each GB of storage provisioned. This means that 1TB of provisioned storage (which in today’s world is rather small) would take 1GB of RAM plus the requirements of running the Ceph daemons. For our low memory footprint, only provision the storage that you’ll need.

Before starting the install, you’ll need a couple of things in place:

  • SSH Keys are set up between all nodes in your cluster – see this post for information on how to set up SSH Keys. For security it’s good practice to set up a new user on all machines you’re going to install Ceph onto and use it to run Ceph. The key should also be copied to all machines using the ssh-copy-id command.
  • NTP is set up on all nodes in your cluster to keep the time in sync. You can install it with: apt-get install ntp

The following commands are for installing Ceph on Debian (wheezy) and should be executed on all machines that need to run Ceph. In our example, these commands will be executed on Server 1Server 2 and Server 3.

First let’s add the release key and repositories to the apt package manager. Run the following as root:

wget --no-check-certificate -q -O- 'https://git.ceph.com/git/?p=ceph.git;a=blob_plain;f=keys/release.asc' | apt-key add -
echo deb http://download.ceph.com/debian-firefly/ $(lsb_release -sc) main | tee /etc/apt/sources.list.d/ceph.list

Next let’s update our apt cache and install Ceph and a few other bits.

apt-get update && apt-get install ceph-deploy ceph ceph-common

Setup and configuring for minimal resource requirements

The next step should be done on just one of your Ceph machines. This will create the monitor service and make each machine aware of the other machines running Ceph.

The command references each machine you’re going to be running Ceph on by hostname or DNS entry. Before running the command, make sure that all of your machines resolve via DNS or hosts file. Because I’m only running this in a lab, I’ve used the hosts file route and added an entry to each machine in the hosts file of all Ceph machines.

vi /etc/hosts

Add your Ceph machine IP and hostnames.

10.10.10.1 ceph1
10.10.10.2 ceph2
10.10.10.3 ceph3

You can test that each machine can see the others by using the ping command. If it works then you should be in business!

ping ceph2
ping ceph3

Once you’re happy that all machines can reference the other machines then run the ceph-deploy command:

ceph-deploy new ceph1 ceph2 ceph3

If you haven’t used your ssh keys since setting them up you may be presented with the following warning. Just type yes to continue.

The authenticity of host 'ceph1 (10.10.10.1)' can't be established.
ECDSA key fingerprint is 66:44:a8:90:e2:8e:12:0e:05:4a:c4:93:a1:43:d1:fd.
Are you sure you want to continue connecting (yes/no)? yes
Warning: Permanently added 'ceph1' (ECDSA) to the list of known hosts.

We now need to configure Ceph with our low resource settings. These settings are not performance driven, but instead set to minimise system resources.

See ceph.conf for the script and add the content to the ceph.conf file

vi ~/ceph.conf

Create the initial mds daemons, monitor daemons and set the proper permissions on the keyring file.

ceph-deploy mon create-initial
ceph-deploy admin ceph1 ceph2 ceph3
ceph-deploy mds create ceph1 ceph2 ceph3

ssh ceph1 "chmod 644 /etc/ceph/ceph.client.admin.keyring"
ssh ceph2 "chmod 644 /etc/ceph/ceph.client.admin.keyring"
ssh ceph3 "chmod 644 /etc/ceph/ceph.client.admin.keyring"

Test Ceph is deployed and monitors are running

At this point it’s good to take a step back and check everything is up and running. We’ve still not assigned any storage to our Ceph cluster so we can’t run it yet, but we should have the monitor daemons running and the cluster configuration be deployed on all servers.

Run the below command and take a look at the output.

ceph -s

The output should show

cluster 51e1ddff-ff28-4f58-af7e-e94448e5324b
   health HEALTH_ERR 192 pgs stuck inactive; 192 pgs stuck unclean; no osds
   monmap e1: 3 mons at {ceph1=10.10.10.1:6789/0,ceph2=10.10.10.2:6789/0,ceph3=10.10.10.3:6789/0}, election epoch 6, quorum 0,1,2 ceph1,ceph2,ceph3
   osdmap e1: 0 osds: 0 up, 0 in
    pgmap v2: 192 pgs: 192 creating; 0 bytes data, 0 KB used, 0 KB / 0 KB avail
   mdsmap e8: 1/1/1 up {0=web1=up:active}, 2 up:standby

As you can see, three Ceph servers are referenced on port 6789 which is the monitor daemon port number.

Add storage to the Ceph cluster

We’ve got our Ceph cluster, and we’ve got our storage device that we created as the first step, it’s time to put the two together. Run the below commands on the same machine that you ran the above steps on. You’ll need to replace /dev/sda with the block device on each ceph machines that you’d  like to use. Note that the block device (sda) does not need to be the same on all machines.

ceph-deploy osd create --fs-type ext4 ceph1:/dev/sda
ceph-deploy osd create --fs-type ext4 ceph2:/dev/sda
ceph-deploy osd create --fs-type ext4 ceph3:/dev/sda

Or…

You can use a directory as storage for Ceph, rather than a block device.

If you’re following this tutorial and creating a loop device to use with Ceph then you’ll need to ensure there is a filesystem on the loop0 device and that it’s mounted. You can skip these next step if you are just using an existing directory.

Run the below commands (if you’re using a loop device) on each of the machines that has a loop device you’d like to use. We’re assuming that you’re loop device is loop0. For this example we’ll run it on each of the three machines; ceph1, ceph2 and ceph3.

mkfs.ext4 /dev/loop0
mkdir /mnt/ceph-backing0
echo "/dev/loop0 /mnt/ceph-backing0 ext4 defaults 1 1" >> /etc/fstab
mount /mnt/ceph-backing0

You can use a directory path on the Ceph machine as the OSD device. This may be an option if you’re in an OpenVZ or Docker container that doesn’t allow you to pass through block devices.

ceph-deploy osd prepare ceph1:/mnt/ceph-backing0
ceph-deploy osd prepare ceph2:/mnt/ceph-backing0
ceph-deploy osd prepare ceph3:/mnt/ceph-backing0

And then activate the storage:

ceph-deploy osd activate ceph1:/mnt/ceph-backing0
ceph-deploy osd activate ceph2:/mnt/ceph-backing0
ceph-deploy osd activate ceph3:/mnt/ceph-backing0

Mount a Ceph device as a folder

That’s the server side done! The last step to using our Ceph storage cluster is to mount the cluster to a mountpoint on the local filesystem. Here we’re going to use /mnt/ha-pool as the mount point but you can change that to whatever you’d like. Run these commands on any machines that you’d like to mount the Ceph volume on.

First create the mount point where the Ceph storage will be accessible from.

mkdir /mnt/ha-pool

Then we need to export the key so that the ceph-client can authenticate with the Ceph daemon. You could turn authentication off, or even create a non-admin user secret but for this tutorial we’ll just use the admin user.

ceph-authtool --name client.admin /etc/ceph/ceph.client.admin.keyring --print-key >> /etc/ceph/admin.secret

Then run the below command to add an entry to your fstab file so that the Ceph volume will be automatically mounted on machine start. This will mount the Ceph volume at /mnt/ha-pool.

echo "ceph1,ceph2,ceph3:/ /mnt/ha-pool/ ceph name=admin,secretfile=/etc/ceph/admin.secret,noatime 0 2" >> /etc/fstab

Finally run the mount command

mount /mnt/ha-pool

One last check to make sure you’re up and running:

df -h | grep ha-pool
10.10.10.1,10.10.10.2,10.10.10.3:/                    6G   3G   3G  54% /mnt/ha-pool

And that’s it! You have a working Ceph cluster up and running!


Manually Install Frappe on Ubuntu 14.04 With a Remote SQL Server

Get Social!

frappeFrappe is a full stack web framework based on Python and Javascript which can be used to build and deploy web applications. The main focus of this post is to set up a Frappe environment that can be used for ERPNext.

Before starting, install MariaDB 10.x on a remote host (or local, but that’s less common in a production environment) as we’ll use that later.

Create a user for Frappe – here we’ll use frappe but you can change this for anything you like. If you do change the user remember to update the home directory.

useradd -d /home/testuser -m -d /home/frappe frappe

Set the password for the frappe user with passwd.

passwd frappe

Install the required dependencies. Notice that we’ve not included an SQL server as we’ll use a remote MariaDB SQL Server.

apt-get update
apt-get install -y python-dev python-setuptools build-essential python-mysqldb git ntp vim screen htop libmariadbclient-dev  libxslt1.1 libxslt1-dev redis-server libssl-dev libcrypto++-dev postfix supervisor python-pip fontconfig libxrender1 libxext6 xfonts-75dpi xfonts-base cron mysql-client curl nginx

Download and install the latest version of wkhtmltopdf from Sourceforge.

cd /tmp/
wget http://sourceforge.net/projects/wkhtmltopdf/files/0.12.2.1/wkhtmltox-0.12.2.1_linux-trusty-amd64.deb/download
dpkg -i download
apt-get -f -y install

Download Frappe from Github as the frappe user.

su - frappe
cd /home/frappe
git clone https://github.com/frappe/bench bench-repo
exit

Run the pip installer for Frappe.

pip install -e bench-repo

Create a new Bench as the frappe user.

su - frappe
bench init frappe-bench && cd frappe-bench

Add the default site configuration file with the remote SQL database hostname/ IP and port number.

vi /home/frappe/frappe-bench/sites/common_site_config.json

And add:

{
 "db_host": "database.host.com",
 "db_port": "3306"
}

Before you create any sites, you’ll need to apply a few settings to your SQL server. This guide assumes you have a remote MariaDB SQL Server – log into it and add the below to your my.conf file.

vi /etc/mysql/my.conf
[mysqld]
innodb-file-format=barracuda
innodb-file-per-table=1
innodb-large-prefix=1
character-set-client-handshake = FALSE
character-set-server = utf8mb4
collation-server = utf8mb4_unicode_ci

And restart your SQL server for the changes to take affect.

service mysql restart

Copy the Supervisor config file into place so that Frappe automatically starts up with the system.

cp /home/frappe/frappe-bench/config/supervisor.conf /etc/supervisor/conf.d/




Visit our advertisers

Search

Quick Poll

Do you use GlusterFS in your workplace?

Visit our advertisers
